Automatic Control Fully Automatic Rotary Drum Filter For Cultivating With Online Support

1 Meter
MOQ
$6,875.00(1 - 1 Meters) $6,500.00(>=2 Meters)
preço
Automatic Control Fully Automatic Rotary Drum Filter For Cultivating With Online Support
Características Galeria Descrição de produto Peça umas citações
Características
Especificações
Condition: New
Applicable Industries: Manufacturing Plant, Farms
Showroom Location: Philippines, Indonesia
Video outgoing-inspection: Provided
Machinery Test Report: Provided
Marketing Type: Hot Product 2021
Warranty of core components: 1 Year
Core Components: Gearbox, Pressure vessel, Pump, Gear, Bearing, Engine, Motor, PLC
Material: Wooden Case
Weight: 40kg-850kg, 400kg
Size: 145*105*110cm
Warranty: 1 Year
Productivity: 750L/Hour
Weight (KG): 400 kg
Application: Farming
Product name: Drum Filter
Feature: Automatic Control
Brand: Water Master
Customized: Available
power: 1.85kw
Flow rate: 0-250m3/h
Shell Material: PP
After Warranty Service: Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location: Philippines, Indonesia
After-sales Service Provided: Video technical support, Field installation, commissioning and training, Field maintenance and repair service, Free spare parts, Online support
Informação básica
Condições de Pagamento e Envio
Packaging Details: Wooden case
Supply Ability: 1 Set/Sets per Month
Descrição de produto
Products Description

Drum Filter

The drum filter is mainly composed of four parts: tank component, roller component, backwash component and liquid level automatic control component. It is made of non-toxic seawater corrosion-resistant high-quality engineering plastic materials. A stainless steel filter screen is fixed on the rotatable drum, and the tiny suspended substances in the water are separated and filtered through the screen and finally achieve solid-liquid separation. During the filtering process, small suspended particles in the water will cause the screen to be blocked. When the screen is blocked, the liquid level automatic control component works, and the backwash water pump and roller reducer automatically start working to make the screen timely cleaning to keep the equipment in good working condition. Our company's drum filter is designed for the problems that the existing filters cannot work automatically, is not resistant to corrosion, the screen is easy to break, easy to block, equipment failure rate is high, and maintenance and operation are difficult. It is one of the solid-liquid separation technologies in the early stage of water treatment in the aquaculture system. This product purifies the water by separating the solid waste in the aquaculture water to achieve the purpose of recycling.
Details Images
Features
1. Durable, safe and energy saving 2. Replacing the water pressure requirements of the sand tank, it is energy-saving, non-blocking, and can run continuously, effectively filtering impurities in the water. Various sizes can be customized.
Product Paramenters
Capacity
Dimension
Tank
Screen
Filtration Accuracy
Drive Motor
Backwash Pump
Inlet
Discharge
Outlet
10m3/h
95*65*70cm
Brand new PP
SS316L
200 mesh
（80Micron）
220V,120w
50Hz/60Hz
SS304
220V,370w
63mm
50mm
110mm
20m3/h
100*85*83cm
110mm
63mm
110mm
30m3/h
100*95*95cm
110mm
63mm
110mm
50m3/h
120*100*100cm
160mm
63mm
160mm
100m3/h
145*105*110cm
160mm
63mm
200mm
150m3/h
165*115*130cm
SS304
220V,550w
200mm
63mm
250mm
200m3/h
180*120*140cm
SS304
220V,750w
200mm
63mm
250mm
300m3/h
230*135*150cm
SS316L
220/380V,
750w,
50Hz/60Hz
75mm
400m3/h
265*160*170cm
SS304
220V,1100w
75mm
500m3/h
300*180*185cm
SS304
220V,2200w
75mm
Working Principle
The working principle of the drum filter is as follows: When the water containing tiny suspended substances enters the roller, the tiny suspended substances are intercepted by the stainless steel screen, and after filtering, the water without suspended substances enters the reservoir.When the suspended substances in the roller accumulates to a certain amount, it will cause the water permeability of the screen to decrease, causing the water level in the roller to rise. When the water level rises to the set high water level, the liquid level automatic control component works. At this time, the backwash water pump and the roller reducer automatically start working at the same time. The high-pressure water of the backwash water pump is subjected to high-pressure cleaning of the rotating screen. After washing,suspended substances flows into the dirt collection tank and is discharged through the sewage pipe.After the screen is cleaned, the water permeability of the screen rises and the water level drops. When the water level drops to the set low water level, the backwash water pump and the roller reducer will automatically stop working, and the filter will enter a new a working cycle.
Application
1. Factory indoor aquaculture farms, especially high-density aquaculture farms. 2. Aquaculture nursery ground and ornamental fish culture base; 3. Seafood temporary maintenance and transportation; 4. Water treatment of aquarium project, seafood fish pond project, aquarium project and aquarium project.
